ISO 鏈號ISO chain
No.

ANSI 鏈號ANSI chair
No.

節距Pitch

滾子直徑Roller
diameter

內節內寬Width
between
inner plates

銷軸直徑Bearing pin
body
diameter

銷軸長度Width
over
bearing
pin

連接銷軸長度With over connecting pin

內鏈板高度inner
piate
depth

排距Transverse pitch

鏈板厚度Plate
thickness

極限拉伸載荷Ultimate
tensile
strength

平均拉伸載荷Average
tensile strength

每米重量Weight
per
meter

P

dl
max

bl
min

d2
max

L
max

Lc
max

h2
max

Pt

T

Q
min

-
Q

q

mm

mm

mm

mm

mm

mm

mm

mm

mm

KN

KN

kg/m

*04C-1

25

6.35

3.3

3.1

2.31

8

9.9

6.02

-

0.8

3.50

4.4

0.14

*06C-1

35

9.525

5.08

4.68

3.58

12.4

14.4

8.70

-

1.3

7.90

10.4

0.33

285-1

41

12.7

7.77

6.25

3.58

13.75

16.0

9.91

-

1.25

6.70

11.8

0.41

08A-1

40

12.7

7.95

7.85

3.96

16.6

19.1

12.07

-

1.5

13.8

17.8

0.62

10A-1

50

15.875

10.16

9.4

5.08

20.7

23.3

15.09

-

2.0

21.8

28.0

1.02

12A-1

60

19.05

11.91

12.57

5.94

25.9

28.6

18.08

-

2.44

31.1

39.0

1.50

16A-1

80

25.4

15.88

15.75

7.92

32.7

38.0

24.13

-

3.26

55.6

71.5

2.60

20A-1

100

31.75

11.91

18.90

9.53

41.1

44.9

30.18

-

4.0

86.7

102.0

3.91

24A-1

120

38.1

15.88

25.22

11.10

50.8

56.1

36.20

-

4.8

124.6

156.9

5.62

28A-1

140

44.45

25.4

25.22

12.70

54.9

60.8

42.24

-

5.65

169

210.8

7.50

32A-1

160

50.8

28.58

31.55

14.27

65.5

72.6

48.26

-

6.45

222.4

269.7

10.10

36A-1

180

57.15

35.71

35.48

17.46

72.8

83.0

54.31

-

7.25

280.2

327.8

13.45

40A-1

200

63.5

39.68

37.85

19.85

80.3

90.5

6.33

-

8.0

347.0

410.0

16.15

48A-1

240

76.2

47.63

47.35

23.81

95.5

106.0

72.39

-

9.5

500.4

585.4

23.2

*04C-2

25-2

6.35

3.3

3.1

2.31

14.5

16.5

6.02

6.4

0.8

7.0

8.8

0.28

*06C-2

35-2

9.525

5.08

4.68

3.58

22.5

24.5

8.70

10.13

1.3

15.8

20.8

0.63

08A-2

40-2

12.7

7.95

7.85

3.96

31.0

33.5

12.07

14.38

1.5

27.6

35.6

1.12

10A-2

50-2

15.875

10.16

9.4

5.08

38.9

41.3

15.09

18.11

2.0

43.6

56.0

2.00

12A-2

60-2

19.05

11.91

12.57

5.94

48.8

51.5

18.08

22.78

2.44

62.3

82.4

2.92

16A-2

80-2

25.4

15.88

15.75

7.92

62.7

62.7

24.13

29.29

3.26

111.2

143.0

5.15

20A-2

100-2

.1.75

19.05

18.90

9.53

76.4

83.1

30.18

35.76

4.0

173.5

204.2

7.80

24A-2

120-2

.8.1

22.23

25.22

11.10

96.3

101.6

36.20

45.44

4.8

249.1

313.8

11.70

28A-2

140-2

44.45

25.40

25.22

12.70

103.6

109.4

42.24

48.87

5.65

338.1

421.7

15.14

32A-2

160-2

50.8

28.58

31.55

14.27

123.3

130.2

48.26

58.55

6.45

444.8

539.4

20.14

36A-2

180-2

57.15

35.71

35.48

17.46

138.6

148.5

54.31

65.84

7.25

560.5

655.7

29.22

40A-2

200-2

63.5

39.68

37.85

19.85

151.9

161.5

6.33

71.55

8.0

693.9

820.0

32.24

48A-2

240-2

76.2

47.63

47.35

23.81

183.4

193.9

72.39

87.83

9.5

1000.8

1170.8

45.23

*06C-3

35-3

9.525

5.08

4.68

3.58

32.7

34.7

8.7

10.13

1.3

23.7

30.0

1.05

08A-3

40-3

12.7

7.95

7.85

3.96

45.4

48.0

12.07

14.38

1.5

41.4

51.2

1.90

10A-3

50-3

15.875

10.16

9.4

5.08

57.0

59.8

15.09

18.11

2.0

65.4

82.0

3.09

12A-3

60-3

19.05

11.91

12.57

5.94

71.5

75.6

18.08

22.78

2.44

93.4

115.0

4.54

16A-3

80-3

25.4

15.88

15.75

7.92

91.7

96.8

24.13

29.29

3.26

166.8

208.0

7.89

20A-3

100-3

31.75

19.05

18.90

9.53

112.2

117.2

30.18

35.76

4.0

260.2

310.0

11.77

24A-3

120-3

38.1

22.23

25.22

11.10

141.7

148.3

36.20

35.44

4.8

373.7

470.7

17.53

28A-3

140-3

44.45

25.4

25.22

12.70

152.2

158.3

42.24

48.87

5.65

507.1

632.5

22.20

32A-3

160-3

50.8

28.58

31.55

14.27

181.8

188.6

48.26

58.55

6.45

667.2

809.0

30.02

36A-3

180-3

57.15

35.71

35.48

17.46

204.4

214.5

54.31

65.84

7.25

840.7

983.6

38.22

40A-3

200-3

63.5

39.68

37.85

19.85

223.5

232.9

60.33

71.55

8.0

1040.9

1230.0

49.03

48A-3

240-3

76.2

47.63

47.35

23.81

271.2

281.8

72.39

87.83

9.5

1501.3

1756.2

71.60
